Silicon Plywood
Our Brochures
Silicon Plywood
When it is a matter of plywood, SILICON Ply is by far, the undisputed leader among the quality brands. The signature plywood products are used extensively in commercial and domestic settings. SILICON plywood is affordable yet durable and offer unmatched strength and oodles of style to complement modern, urban living. SILICON ply is manufactured with utmost care with the high quality selected raw materials. High density Plantation timber is used to manufacture the SILICON ply, each core veneer is bonded with high solid content resin made by experts of resin formulation. It is warp resistant plywood which maintains its original shape over the years and treated specific chemical to make it termite and borer resistant.
SILICON Ply offer wide range of products to meet up the requirement of different uses. It is perfect for the interior, exterior and other heavy duty uses
Silicon Plywood Types
- SILICON GOLD (IS:710)
- SILICON PREMIUM (IS:303)
- SILICON ULTIMA (IS:303)
- SILICON ULTIMA (IS:303)
- Size : 8x4, 8x3, 7x4, 7x3, 6x4, 6x3
- Thickness : 19mm, 16mm, 12mm, 9mm, 6mm
Completely water proof Marine grade plywood made with 100% GURJAN timber. Perfect for exterior use.
Boiling water resistant BWR grade plywood made with GURJAN timber.
BWR Grade plywood with ultimate strength, made with high density RED wood and POPLAR core.
MR Grade plywood for interior furniture and wood working, made with high density RED wood and POPLAR core.
| TECHNICAL SPECIFICATIONS IS:303 | |||
|---|---|---|---|
| # | Test | Is Requirement | Observed Value |
| 1 | Moisture Content Dimension | 5%-15% Ltength+5mm, Width+2mm, Thickness >= 6mm- +5%,< 6mm -+ 10% | 8% Within limit |
| 2 | Sp. Gravity | - | >7 |
| 3 | Resistance to Water (3 cycles of 8 hr Boillng & 16 Hr Drying at 65°C) -Adhesion to plies | Min. Pass Standard | Excellent |
| 4 | Resistance to Micro-organism -Adhesion to plies | Min. Pass Standard | Excellent |
| 5 | Static Blending Test | - | - |
| Modulus of Elasticity -Along the grain Avg. -Across the grain Avg. Modulus of Rupture -Along the grain Avg. -Across the grain Avg. |
Min. 5000 N/sq.mm Min. 2500 N/sq.mm Min. 40 N/sq.mm Min. 20 N/sq.mm |
Min. 6500 N/sq.mm Min. 3000 N/sq.mm Min. 56 N/sq.mm Min. 30 N/sq.mm |
|
MARINE PLYWOOD (IS:710) BWP
| TECHNICAL SPECIFICATIONS IS:710 | |||
|---|---|---|---|
| # | Test | Is Requirement | Observed Value |
| 1 | Moisture Content | 5%-15% | 8% |
| 2 | Glue Sheer Strength (Dry State) |
Min. Ind. 1100 N Min. Avg 1350 N |
1350 N 1500 N |
| 3 | Adhesion to plies | Min. Pass Standard | Excellent |
| 4 | Glue Sheer Strength (after 72 hrs. Boiling) |
Min. Ind. 800 N Min. Avg 1000 N |
1150 N 1250 N |
| 5 | Tensile Strength -Along the Grain -Across the Grain -Sum of Tensile Strength |
4200 N / sq. mm 2500 N / sq. mm 2500 N / sq. mm |
5500 N / sq. mm 3950 N / sq. mm 9400 N / sq. mm |
| 6 | Static Bending Strength (A) Modulus of Rupture -Along the grain. -Across the grain. (B) Modulus of Elasticity -Along the grain. -Across the grain. | 50 N/sq.mm 30 N/sq.mm 7500 N/sq.mm 4000 N/sq.mm |
65 N/sq.mm 40 N/sq.mm 8305 N/sq.mm 4170 N/sq.mm |
